Controller DSE890 for Deep Sea With GPS GSM Antennas

Controller DSE890 for Deep Sea With GPS GSM Antennas

Part Number:
DSE890

Application
For GPS & GSM Antennas

Specification
DC SUPPLY

CONTINUOUS VOLTAGE RATING
8 V to 35 V Continuous

CRANKING DROPOUTS
Able to survive for 50 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved without the need for internal batteries

MAXIMUM OPERATING CURRENT
GSM:700 mA at 12 V
?? ? 450 mA at 24 V
GSM & GPS:700 mA at 12 V
??????? ? ?? 450 mA at 24 V
Ethernet:200 mA at 12 V
??????? 110 mA at 24 V
Ethernet & GPS:700 mA at 12 V
???????????? ?? 450 mA at 24 V

MAXIMUM STANDBY CURRENT
GSM:270 mA at 12 V
?? ? 150 mA at 24 V
GSM & GPS:270 mA at 12 V
???????????????????? 150 mA at 24 V
Ethernet:150 mA at 12 V
?????????????? ?? 90 mA at 24 V
Ethernet & GPS:270 mA at 12 V
?????????????????????????? 150 mA at 24 V
COMMUNICATIONS
USB?(Single DSE Controller)
RS232 (Single DSE Controller)
RS485 (Multiple DSE?Controllers)
Ethernet (Multiple DSE?Controllers)

Environmental Testing Standards
ELECTRO-MAGNETIC? COMPATIBILITY
BS EN 61000-6-2
EMC Generic Immunity Standard for the Industrial Environment.
BS EN 61000-6-4
EMC Generic Emission Standard for the Industrial Environment.
ELECTRICAL SAFETY
BS EN 60950
Safety of Information Technology Equipment, including Electrical Business Equipment.
TEMPERATURE
BS EN 60068-2-1
Ab/Ae Cold Test -30C.
BS EN 60068-2-2
Bb/Be Dry Heat +70C.
VIBRATION
BS EN 60068-2-6
Ten sweeps in each of three major axes.
5 Hz to 8 Hz @ +/-7.5 mm, 8 Hz to 500 Hz gn.
HUMIDITY
BS EN 60068-2-30
Db Damp Heat Cyclic 20/55 95% RH 48 Hours.
BS EN 60068-2-78
Cab Damp Heat Static 40 93% RH 48 Hours.
SHOCK
BS EN 60068-2-27
Three shocks in each of three major axes 15 gn in 11 ms.

Note:
When placing an order, please contact us with engine /air compressor nameplate so that we can check it (or prepare the operating procedures more accurately for you).
