AVR SX440 Module Automatic Voltage Regulator For NEWAGE Stamford Generator DHO

AVR SX440 Module Automatic Voltage Regulator For NEWAGE Stamford Generator DHO

SPECIFICATION:
Sensing Input:
Voltage: 190-264V ac max, 1 phase 2 wire
Frequency: 50-60HZ nominal
Power input:
Voltage: 140-220 V ac max, 3 phase,3 wire
Current: 3A/phase
Frequency: 100-120HZ nominal
Out put:
Voltage: max 120V/DC
Current: continuous 2.7A/DC
Intermittent 6A for 10 secs
Resistance: 15 ohms minimum
Regulation:?+/-1%
Thermal drift:?0.03% per deg.C change in AVR ambient
Soft start pamp time:?3 sec
Typical system response:
AVR respone: 10ms
Filed current to 90%: 80ms
Machine Volts to 97%: 300ms
External voltage adjustment:?+/-10% with 1k ohm 1W trimmer
Under frequency protection:
Set point: 95%HZ
Slope: 170% down to 30HZ
Unit power dissipation:?12 watts maximum
Analogue input:
Maximum input: +/-5V/DC
Sensitivity 1V for 5% Generator Volts(adjustable)
Input resistance 1k ohm
Quadrature droop input:
10 ohms burden
Max.sensitivity:0.07A for 5% droop OPF
Max.input:0.33A
Over excitation protection:
Set point:75V/DC
Time relay:10 sec
Environmental:
Vibration:20 -100HZ (50mm/sec), 100Hz -2kHz
Operating temperature: -40oC to +70 oC
Relative Humidity: 95%
Storage temperature: -55oC to +80oC

Description:
1.SX440 is a two-phase sensed Automatic Voltage Regulator(AVR) and forms part of the excitation system
for a brushless generator.
2.The AVR senses the voltage in the main generator winding and control the power fed to the exciter stator and
hance the main rotor to maintain the generator output voltage within the specified limits, compensating for load sprrd,temperature and power factor of the generator.
3.Excitation power is derived from a three-phase permanent magnet generator(PMG),to isolate the AVR control circuits from the effects of nonlinear loads and to reduce radio frequency interference on the generator terminals. sustained generator short circuit current is another feature of the PMG system.
4.The AVR has the faclity for droop CT connection,to allow parallel running with other similarly equipped generators.

Packing:
AVR SX440--------1Piece
English Manual----1Piece
Carring Box--------1Piece
